Sterilization at Standard 121'c & 134'c cycles.
PLC based automation, with 10 per programmed cycles and additional user defined cycles.
SS construction for door, chamber , jacket and stream generator.
Automation Sliding doors sealed with the help of a silicone door gasket.
State of the art Supervisory Control & Data Acquisition.
Software allows remote operation & monitoring of the machine.
Reports generated by the software in any data file.
Audio & Display of Alarm Facility.
Visual Display of HMI Screen for error messages.
Security System by Provided Supervisory codes and Password Protection.
| Chamber | Sr. No. | Width | Height | Depth | Volume(m2/ft) | Capacity(liter) |
|---|---|---|---|---|---|
| 1 | 450mm | 450mm | 900mm | 0.18/6.75 | 180 |
| 2 | 600mm | 600 | 1200mm | 0.432/16 | 432 |
| 3 | 600mm | 600 | 1500mm | 0.54/20 | 540 |
| 4 | 900mm | 600mm | 1500mm | 0.81/20 | 810 |
